| Image Sensor |
1/2.9” 4MP PS CMOS Image Sensor (0.8758 centimeters) |
| Effective Pixels |
2688 (H) × 1520 (V) |
| Minimum Illumination |
0.06 lux@F1.6 (Color, 30 IRE), 0.006 lux@F1.6 (B/W, 30 IRE), 0 lux (IR on) |
| Angle Adjustment |
Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360° |
| Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| White Balance |
Auto, Natural, Street lamp, Outdoor, Manual, Regional custom |
| RAM |
128 MB |
| ROM |
128 MB |
| DORI Distance |
Lens 3.6 mm: 85.4 m (Detect), 34.2 m (Observe), 17.1 m (Recognize), 8.5 m (Identify) |
| Gain Control (AGC) |
Auto/ Manual |
| Lens Type |
Fixed-focal |
| Max. Aperture |
F1.6 |
| Lens Mount |
M12 |
| Close Focus Distance |
1.7 m |
| Lens |
3.6mm fixed Lens |
| IR Number |
1 (Multi-core (IR + warm) light) |
| IR |
IR Range of 30 Mtr. |
| Smart Illumination |
Support |
| IR Control |
Auto, Manual |
| Angle of view |
3.6 mm: H: 78°, V: 40°, D: 93° |
| Back Light Compensation |
BLC/ HLC/ WDR(120dB) |
| Resolution |
4MP (2688 x 1520)/ (2560 × 1440), 3MP (2304 × 1296), 2MP (1920 × 1080), 1.3MP (1280 × 960), 720p (1280 × 720), D1 (704 × 576 / 704 × 480), VGA (640 × 480), CIF (352 × 288 / 352 × 240) |
| Video Compression |
Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by sub stream) |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Video Format |
PAL/NTSC |
| Stream Capability |
Triple stream |
| Frame Rate |
Main stream: 4MP (2688 × 1520)@1-25/30fps/ (2560 × 1440)@1-25/30 Sub stream 1: 720P( 1280 × 720), D1 (704 × 576)@1–25 fps/ (704 × 480)@1–30 fps, VGA(640 × 480)@1-30fps, CIF (352 × 240)@1-30fps, (352 × 288) @1-25fps Sub stream 2: D1 (704 × 576)@1–25 fps/ (704 × 480)@1–30 fps, VGA(640 × 480)@1-30fps, CIF (352 × 240)@1-30fps/ (352 × 288) @1-25fps |
| Privacy Mask |
8 areas |
| OSD |
Camera title, Date & Time |
| Audio Compression |
G.711a, G.711Mu, PCM, G.726, AAC |
| Bit Rate Control |
CBR/ VBR |
| Bit Rate |
H.265: 3 kbps-6144 kbps, H.264: 8 kbps-6144 kbps |
| Protocol |
SFTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T), unicast, multicast |
| Day/Night |
Auto(ICR)/Color/B/W |
| Ethernet |
RJ-45 (10/100 Base-T) |
| Alarm Event |
Network disconnection, IP conflict, illegal access, Motion detection, Video tampering, Audio detection, Security exception, SMD (human & Motor Vehicle) |
| Mirror Function |
Support |
| Smart search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Smart IR |
Support |
| Image Rotation |
4MP only support 0°/180° 2MP & lower will support 0°/90°180°/270° |
| User/Host |
6 (Total bandwidth: 36 M) |
| Browser |
IE, Chrome, Firefox |
| Iris Control |
Fixed |
| Certificates |
ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report |
| Power Source |
12 VDC/ PoE (802.3af) |
| Power Consumption |
Basic: 1.6 W (12 VDC), 2.0 W (PoE); Max. : 3.7 W (12 VDC), 4.7 W (PoE) (H.265 + intelligence on + WDR+ warm light intensity |
| Weatherproof Standard |
IP67 |
| Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity |
≤95%(RH), non-condensing |
| Storage Humidity |
≤95%(RH), non-condensing |
| Dimensions |
162.6 mm × 70 mm× 70 mm |
| Casing |
Metal + Plastic |
| Weight |
220g |
